Metal-Technik 1.6 m rear-mounted street sweeper for compact utility tractors

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Metal-Technik

- Catalogue number: MT160ZU

- Manufacturer's name: MTS2 Sweeper

- Width: 1600 mm

- Width with side brush: 2040 mm

- Length: 1070 mm

- Height: 880 mm

- Weight: 210 kg

- Brush diameter: 300 mm

- Side brush drive: Hydraulic motor

- Water tank capacity: 200 L

- Minimum oil flow: 30 L/min

- Maximum oil flow: 60 L/min

- Maximum oil pressure: 140 bar

- Main drive system: Driven by PTO shaft

- Supported PTO speed: 540 RPM

- Hitch design: Equipped with a terrain-following / contour-adaptation system

- Hopper lifting: Hydraulic collection hopper emptying

- Brush options: Easily replaceable plastic or plastic-metal bristles

- Mounting: Rear 3-point hitch (TUZ), Cat. I small or Cat. I large

- Vehicle compatibility: Designed for aggregation with small carriers, compact tractors, small loaders, and mini machines

Extra Cost:

- Water Tank

The water tank in road and municipal sweepers is an integral part of the dust suppression sprinkling system, which helps reduce airborne dust and improves cleaning efficiency. Made of corrosion-resistant plastic or steel, it features high resistance to mechanical damage. Its capacity, typically ranging from 100 to 500 liters, ensures long operation without the need for frequent water refills. The tank is equipped with connection ports for the spraying system and an inlet for easy filling. Some models feature water level indicators and a filtration system to prevent clogging of the spray nozzles.

- Side Brush

The side brush is a key component of mechanical sweepers, responsible for removing debris from hard-to-reach areas such as curbs, corners, or building walls. Made of durable synthetic fibers or a mixture of plastic and metal wires, it is resistant to abrasion and intensive use. Mounted on a movable arm, it can be hydraulically controlled, allowing it to be raised and lowered as needed. On certain sweeper models, the side brush is additionally equipped with a sprinkling system to limit dust and increase sweeping efficiency.

Detailed Description:

• This road sweeper with a working width of 1600 mm is a modern, versatile device designed for the effective maintenance of cleanliness on various types of surfaces.

• Its solid construction and compact dimensions make it an excellent choice as a tractor sweeper, loader sweeper, or forklift sweeper.

• Due to its lightweight and compact design, it is also perfectly suited for use as a compact utility tractor sweeper or an ATV/quad sweeper, providing precise cleaning of yards, warehouses, sidewalks, and streets.

• The model comes equipped with a hydraulically driven side brush and a main brush with a diameter of 300 mm, allowing for the thorough removal of dust, sand, mud, and leaves—making it highly effective as a leaf sweeper.

• The hydraulic lifting of the collection hopper significantly simplifies operation, increasing user comfort and surface cleaning efficiency.

• The drive, powered via a PTO shaft at a rotational speed of 540 RPM, ensures compatibility with various machines and smooth operation under diverse conditions.

• Thanks to its terrain-following function, the sweeper continuously adapts to surface unevenness, enabling effective performance even on challenging terrain.

• The 200 L water tank effectively eliminates dust, enhancing working comfort and boosting cleaning efficiency.

• With its mounting capability on the rear 3-point hitch (Category I small and Category I large), this unit is widely utilized as a sidewalk sweeper, street sweeper, and road sweeper.

• The oil flow range of 30 to 60 L/min combined with a maximum pressure of 140 bar guarantees high performance and trouble-free operation.

• Easily replaceable plastic or plastic-metal brushes provide durability and easy adaptation to different surface types.

• The sweeper can be utilized year-round, including as a snow sweeper for winter clearing, making it a truly multi-functional tool for cleanliness maintenance regardless of the season.

• It represents a perfect solution for municipal companies, industrial plants, farms, and any users looking for efficient and durable equipment for sweeping roads, squares, and urban areas.
