Metal-Technik street sweeper for compact utility tractor 1.4 m (front-mounted)

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Metal-Technik

- Catalogue number: MT14ZU

- Manufacturer's name: Sweeper MTS

- Width: 1400 mm

- Length: 1520 mm

- Height: 650 mm

- Weight: 200 kg

- Brush diameter: 300 mm

- Actuators: 2

- Waste hopper capacity: 31 L

- Minimum oil flow: 40 l/min

- Maximum oil flow: 60 l/min

- Maximum oil pressure: 140 bar

- Mounting: Front 3-point hitch / TUZ (Municipal: Cat. 0, Cat. I small, or Cat. I large)

- Hitch alignment: Equipped with terrain-following system (contour adapting)

- Hopper emptying: Hydraulic lift

- Sweeper angling: Hydraulic turn/angling

- Functionality: Sweeping-away function

- Dust reduction: Rubber shroud between the brush housing and the hopper to minimize rising dust

- Brush options: Easily replaceable plastic or mixed plastic-and-metal bristles

- Drive type: Driven by PTO shaft (Wałek WOM)

- PTO rotation options: Clockwise / Counterclockwise (right / left)

- PTO speeds: 540 RPM, 1000 RPM, and 2000 RPM

- Application suitability: Designed for small machines, small tractors, and small loaders

Extra Cost:

- Water Tank

A key element of the spraying system in road and municipal sweepers, which helps reduce dusting and increase cleaning efficiency. Made of durable materials resistant to corrosion and damage, it ensures reliable operation even in demanding conditions. Its capacity, usually ranging from 100 to 500 liters, allows for longer use without the need for frequent water refills. The tank design includes a convenient filler inlet, connections to the spraying system, and a filtration system that prevents nozzles from clogging. In some models, it is equipped with a water level indicator, making it easier to control its consumption during work.

- Side Brush

An essential component of sweepers, designed for the effective cleaning of hard-to-reach places such as curbs, corners, and roadsides. Made of durable synthetic fibers or a mixture of plastic and metal fibers, it ensures high wear resistance and sweeping efficiency. Mounted on a movable arm, it can be hydraulically controlled, allowing for its adjustment and adaptation to different types of surfaces. In many models, the side brush is equipped with a spraying system that reduces dusting and increases the effectiveness of debris removal.

Detailed Description:

• The road sweeper with a working width of 1400 mm is a versatile and efficient device designed for the effective maintenance of cleanliness on various surfaces.

• Thanks to its solid construction and modern solutions, it works well as a sweeper for tractors, loaders, and forklifts.

• Its compact dimensions make it also ideal as a tractor and quad sweeper, making it a practical solution for cleaning squares, warehouse halls, roads, and sidewalks.

• The advanced hydraulic system ensures precise control – it allows for lifting the hopper and its turning, which increases user convenience and cleaning efficiency.

• The device is equipped with a brush with a diameter of 300 mm, thanks to which it effectively removes dust, sand, mud, leaves, and other debris, making it an ideal choice as a leaf sweeper.

• The sweeping-away function facilitates thorough cleaning of even hard-to-reach places, and the rubber shroud placed between the brush housing and the hopper effectively limits the rising of dust, which improves working comfort.

• The sweeper is driven by a PTO shaft that supports both right and left rotations, which increases operational flexibility.

• The possible rotation speeds of the shaft are 540, 1000, and 2000 RPM, allowing it to be used with various machines.

• The municipal 3-point hitch mounting system (category 0, I small, I large) enables quick and convenient installation at both the front and rear of the vehicle, so the sweeper works well as a sidewalk sweeper, street sweeper, and road sweeper.

• The waste hopper with a capacity of 31 liters allows for efficient work without the need for frequent emptying, and easily replaceable plastic or plastic-and-metal brushes guarantee a long service life and the ability to adapt to different types of surfaces.

• A maximum oil pressure of 140 bar and an oil flow in the range of 40-60 l/min ensure high performance and trouble-free operation under all conditions.

• The sweeper can also be used for snow removal during the winter season, making it a multi-functional tool for maintaining cleanliness all year round.

• This is an ideal solution for municipal companies, industrial plants, agricultural farms, and users looking for durable and effective equipment for sweeping streets, squares, roads, and industrial areas.
