WAW-POL high-capacity bucket 11-15 T / 2.4 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: WAW-POL

- Nr katalogowy: WL24LO

- Manufacturer's name: High-capacity bucket

- Width: 2400 mm

- Weight: 250 kg

- Capacity: 0.94 m³

- Shell thickness: 4 mm

- Side plate thickness: 8 mm

- Reinforcement: 10 mm

- Cutting edge: 15x120 mm

- Machine weight class: 11-15 T

- Universal compatibility for any machine

- Hitch upon request: any mounting type available (e.g., Euro, JCB, Manitou, Bobcat, CAT, Weidemann, Tramer, etc.)

Detailed Description:

• The high-capacity bucket featuring a width of 2400 mm and a capacity of 0.94 m³ is an exceptionally durable and efficient attachment designed to operate with machines that have an operating weight ranging from 11 to 15 tons.

• Thanks to its large capacity and robust build, it performs outstandingly when transporting low-density materials, such as silage, bedding, compost, sawdust, manure, grain, organic waste, or snow.

• It is ideal for applications on farms, in municipal enterprises, industry, and during intensive loading operations.

• The bucket's structure is manufactured from durable structural steel resistant to abrasion and mechanical loads, making it a reliable tool even under harsh operating conditions.

• The 4 mm thick shell and reinforced 8 mm thick side plates effectively protect the bucket from damage and deformation when working with large volumes of material.

• A 10 mm thick central reinforcement improves the rigidity of the entire structure, preventing warping during use.

• At the bottom of the bucket, there is a steel working cutting edge measuring 120x15 mm, which acts as the main scraping edge – ensuring effective scooping and scraping of material while offering high resistance to wear.

• The total weight of 250 kg provides excellent stability and an even distribution of forces, which translates into machine performance and operational safety.

• A major advantage of this bucket is its mounting universality – it can be adapted to practically any type of machine.

• Various attachment types are available upon customer request, including Euro, JCB Q-Fit, Manitou, CAT IT, Bobcat, Weidemann, Tramer, and others.

• This flexibility allows the bucket to be successfully used with telehandlers, wheel loaders, front loaders, forklifts, as well as excavators fitted with an appropriate adapter.

• Thanks to its well-thought-out design, increased capacity, and solid workmanship, the 2400 mm high-capacity bucket constitutes an excellent choice for professionals who require a reliable, durable, and multi-purpose attachment for the efficient handling of lightweight yet high-volume materials.

• It will prove its worth in any industry where efficiency and reliability are paramount.
