Agrowow 1.5 m fork with grapple

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: AW15WK

- Manufacturer's name: Krokodyl

- Width: 1500 mm

- Height: 900 mm

- Depth: 900 mm

- Weight: 236 kg

- Capacity: 0.75 m³

- Machine weight class: 3.5-5 T

- Cylinders: 2

- Number of top tines: 6

- Number of bottom tines: 7

- Hitch/Mounting: Euro

- Large opening angle of the upper jaw

Optional Extras:

- Mailleux (MX) hitch

A specialized system designed by the renowned front loader manufacturer – MX. Unlike the popular Euro hitch, it stands out with a different structural design and layout of attachment points. Created for specific loader models of this brand, it ensures a precise fit, robustness, and a durable connection with the equipment.

- Manitou

A technical solution intended for Manitou telehandlers. Designed to operate under demanding conditions and heavy loads, it finds application on agricultural farms, orchards, and in the construction sector where durability and reliability matter.

- Weidemann

A compact mounting system dedicated to Weidemann articulated loaders. It enables quick installation and removal of attachments, which significantly facilitates work. Ideal for light tasks such as animal feeding, cleanup chores, or feed transport on smaller farms.

- JCB hitch (Q-Fit or JCB type)

A system created for use with JCB telehandlers and wheeled loaders. It features high durability and a secure attachment connection even during intensive use. Available in several design variants depending on the machine model.

- SMS hitch (Stoll, Schäffer and others)

A popular and easy-to-use system used on machines from brands such as Stoll, Schäffer, or Ålö. It is highly regarded among users of compact loaders, particularly in Western and Northern European countries, thanks to its versatility and durability.

- Other hitch systems (on request)

Upon individual request, it is possible to manufacture the attachment with a less popular or non-standard hitch type, compliant with the technical requirements of the given machine and user needs.

Detailed Description:

• The 1500 mm wide manure fork with hydraulic grapple (fork-crocodile) is a durable and functional attachment designed to work with loaders with a weight of 3.5 to 5 tonnes.

• It will perform perfectly on medium-sized agricultural farms, service points, and in companies dealing with green area maintenance or municipal management.

• Thanks to its compact design – 900 mm in height and 900 mm in depth – and a capacity of 0.75 m³, it enables efficient handling and loading of various types of organic and loose materials, such as manure, silage, compost, green forage, or plant waste.

• A weight of 236 kg represents a compromise between a robust construction and the lightness necessary when working with smaller machines – it ensures the stability of the attachment while not restricting maneuverability and not causing excessive fuel consumption.

• The solid rear wall of the fork-crocodile protects the material from spilling during transport, which significantly increases working cleanliness and operational efficiency.

• Two hydraulic cylinders located in the rear of the construction are responsible for the powerful and even closing of the upper jaw, making it possible to grip the material securely and controllably even in difficult working conditions.

• The large opening angle of the upper jaw is a huge asset – it allows for easy scooping of material directly against the walls of pens, silos, and other terrain obstacles, permitting operation even in confined spaces.

• The upper section of the attachment is equipped with six tines, and the bottom section with seven – this arrangement and number of working elements ensures effective penetration into the material and its stable retention during movement.

• All structural components are made of durable, high-grade steel resistant to deformation and abrasion, which translates into a long service life and reliability of the device even with intensive use.

• The fork-crocodile features a standard EURO-type hitch, enabling quick mounting to most machines available on the market.

• On request, it is possible to manufacture the attachment with a different hitch type tailored to a specific loader model.

• The 1500 mm model is a perfect combination of compact dimensions and high capacity, offering reliable support in daily loading, transport, and cleanup work – both in the agricultural and municipal sectors.
