Agrowow 1.8 m grab bucket with a clamp

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: AW18SD

- Manufacturer's name: Grab bucket with a clamp - profile cut tines

- Width: 1800 mm

- Height: 950 mm

- Depth: 1000 mm

- Weight: 530 kg

- Capacity: 0.81 m³

- Machine weight class: 7-10 T

- Cylinders: 2

- Number of top tines: 7

- Hitch/Mounting: Euro

- Large opening angle of the upper jaw

Optional Extras:

- Mailleux (MX) hitch

A system designed by the front loader manufacturer – MX. Compared to the standard Euro hitch, it differs in its layout of attachment points and construction. Created with selected models of this brand in mind, it ensures a secure, durable, and tailored connection with the attachment.

- Manitou

A mounting type dedicated to Manitou telehandlers. Adapted for intensive work and heavy loads, it performs perfectly in agriculture, orcharding, and the construction sector.

- Weidemann

A compact system used on Weidemann articulated loaders. It allows for quick and convenient connection of attachments. It is ideally suited for light farm work, including livestock handling or gardening tasks.

- JCB hitch (Q-Fit or JCB type)

A hitch developed with JCB telehandlers and wheeled loaders in mind. It offers a reliable and durable connection, enabling safe work even with high lifting capacities. It is available in several variants depending on the machine model.

- SMS hitch (Stoll, Schäffer and others)

A popular system used on machines from brands such as Schäffer, Stoll, or Ålö. It features a simple design and versatility. It is particularly widespread on compact loaders used in Western and Northern European markets.

- Other hitches (on individual request)

It is possible to adapt the attachment to non-standard or less popular solutions – in accordance with the customer's requirements and the specifications of the specific machine.

Detailed Description:

• The 1800 mm wide grab bucket with a clamp is an advanced working attachment, created for professional use in agriculture, livestock farms, municipal plants, and construction companies.

• It combines a solid structure, high capacity, and modern technical solutions that translate into working comfort and safety.

• With dimensions of 950 mm in height, 1000 mm in depth, and a working volume of 0.81 m³, the bucket handles the movement of loose, lumpy, and organic materials – such as manure, silage, green waste, soil, or loose construction fractions – excellently.

• An unladen weight of 530 kg ensures the appropriate stability and structural rigidity, which is particularly vital when working with larger loads and during intensive operation.

• The attachment is adapted for machines in the 7 to 10-tonne weight class, making it an ideal choice for cooperation with heavier front, articulated, and telehandlers.

• The large opening angle of the upper jaw enables the trouble-free loading of materials directly against the walls of silos, clamps, or narrow feed pens – anywhere precision and operational flexibility matter.

• Two powerful hydraulic cylinders mounted in the rear section of the structure guarantee a secure, strong, and even closing of the upper part.

• This solution allows for the effective gripping of materials and their safe retention during transport, even over rough terrain.

• Additionally, the seven solid lower tines allow for efficient penetration into the mass and precise collection of the load without spilling.

• The high-quality steel used to build the attachment is resistant to abrasion, deformation, and mechanical damage, which ensures a long lifespan and low operational costs.

• The entire structure has been engineered with easy maintenance and quick replacement of wearing components in mind.

• The grab bucket with a clamp comes equipped with a standard EURO-type hitch, which guarantees wide compatibility with most machines available on the market.

• Upon request, it is also possible to manufacture a version with an alternative hitch system, adapted to a specific type of loader.

• The 1800 mm model is the ideal choice for users who require a reliable and efficient tool for intensive work in various conditions – both on farms and in industrial environments.

• Thanks to its well-thought-out design and high functionality, this attachment significantly increases the efficiency of daily transport and loading tasks.
