Agrowow 2.0 m grab bucket with a clamp

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: AW20SD

- Manufacturer's name: Grab bucket with a clamp - profile cut tines

- Width: 2000 mm

- Height: 950 mm

- Depth: 1000 mm

- Weight: 570 kg

- Capacity: 0.9 m³

- Machine weight class: 8-11 T

- Cylinders: 2

- Number of top tines: 8

- Hitch/Mounting: Euro

- Large opening angle of the upper jaw

Optional Extras:

- Mailleux (MX) hitch

A system developed by MX – a manufacturer of front loaders. It features a different structural design and arrangement of attachment points than the Euro standard. Designed specifically for individual MX loader models, it ensures a durable, precise, and secure connection with the attachment.

- Manitou

A hitch type used on Manitou telehandlers. It is adapted to work under heavy loads in demanding conditions. It finds application on agricultural farms, in orchards, and within the construction industry.

- Weidemann

A compact mounting system used on Weidemann articulated loaders. It facilitates quick coupling of attachments and is ideally suited for light duties, such as livestock chores or green area maintenance.

- JCB hitch (Q-Fit or JCB type)

A hitch system dedicated to JCB machines – both telehandlers and wheeled loaders. It provides a reliable and solid attachment connection even with high lifting capacities. It is available in various versions depending on the specific machine model.

- SMS hitch (Stoll, Schäffer and others)

A universal system utilized on equipment from brands such as Stoll, Schäffer, or Ålö. It features an uncomplicated design and high functionality, making it particularly popular for compact loaders in Northern and Western Europe.

- Other hitch systems (on request)

Upon special request from the customer, it is possible to manufacture the attachment to fit less standard hitch types – in accordance with the technical requirements of the specific machine.

Detailed Description:

• The 2000 mm wide grab bucket with a clamp is an advanced working attachment, created for professional use in agriculture, livestock farms, municipal plants, and construction companies.

• It combines a solid structure, high capacity, and modern technical solutions that translate into working comfort and safety.

• With dimensions of 950 mm in height, 1000 mm in depth, and a working volume of 0.9 m³, the bucket handles the movement of loose, lumpy, and organic materials – such as manure, silage, green waste, soil, or loose construction fractions – excellently.

• An unladen weight of 570 kg ensures the appropriate stability and structural rigidity, which is particularly vital when working with larger loads and during intensive operation.

• The attachment is adapted for machines in the 8 to 11-tonne weight class, making it an ideal choice for cooperation with heavier front, articulated, and telehandlers.

• The large opening angle of the upper jaw enables the trouble-free loading of materials directly against the walls of silos, clamps, or narrow feed pens – anywhere precision and operational flexibility matter.

• Two powerful hydraulic cylinders mounted in the rear section of the structure guarantee a secure, strong, and even closing of the upper part.

• This solution allows for the effective gripping of materials and their safe retention during transport, even over rough terrain.

• Additionally, the solid lower tines allow for efficient penetration into the mass and precise collection of the load without spilling.

• The high-quality steel used to build the attachment is resistant to abrasion, deformation, and mechanical damage, which ensures a long lifespan and low operational costs.

• The entire structure has been engineered with easy maintenance and quick replacement of wearing components in mind.

• The grab bucket with a clamp comes equipped with a standard EURO-type hitch, which guarantees wide compatibility with most machines available on the market.

• Upon request, it is also possible to manufacture a version with an alternative hitch system, adapted to a specific type of loader.

• The 2000 mm model is the ideal choice for users who require a reliable and efficient tool for intensive work in various conditions – both on farms and in industrial environments.

• Thanks to its well-thought-out design and high functionality, this attachment significantly increases the efficiency of daily transport and loading tasks.
