Agrowow 2.4 m fork with grapple

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: AW24WK

- Manufacturer's name: Krokodyl

- Width: 2400 mm

- Height: 900 mm

- Depth: 1000 mm

- Weight: 375 kg

- Capacity: 1.2 m³

- Machine weight class: 7-9 T

- Cylinders: 2

- Number of top tines: 10

- Number of bottom tines: 11

- Hitch/Mounting: Euro

- Large opening angle of the upper jaw

Optional Extras:

- Mailleux (MX) hitch

A hitch system designed by MX, specifically intended for their front loaders. Unlike the popular Euro standard, it features a different structural layout and arrangement of mounting points. It guarantees a precise fit for selected machine models, offering robustness, durability, and reliability during daily work.

- Manitou

A dedicated solution for Manitou telehandlers. Engineered for operation under heavy loads and harsh conditions, it finds application in agriculture, orcharding, and construction where durability and dependable performance are essential.

- Weidemann

A compact hitch system used on Weidemann articulated loaders. It enables quick and convenient attachment of equipment, increasing working speed. It is ideal for lighter applications such as animal feeding, feed transport, or cleanup chores.

- JCB hitch (Q-Fit or JCB type)

A system developed specifically for JCB telehandlers and wheeled loaders. It ensures a strong and secure connection with the attachment, even under intensive use. It is available in several variants depending on the machine model.

- SMS hitch (Stoll, Schäffer and others)

A universal mounting system used on machines from manufacturers such as Stoll, Schäffer, or Ålö. It features simplicity, functionality, and a heavy-duty construction. It is frequently chosen by users of compact loaders in Western and Northern Europe.

- Other hitch systems (on request)

It is possible to manufacture the attachment with a custom-fitted hitch type – fully adapted to the specifications of a particular machine and the individual requirements of the user.

Detailed Description:

• The 2400 mm wide manure fork with hydraulic grapple (fork-crocodile) is an exceptionally durable and high-capacity attachment designed to work with loaders with an operating weight of 7 to 9 tonnes.

• It will perform perfectly on large-scale farms, logistics centers, municipal plants, and in industrial applications where efficiency and operational reliability in demanding conditions are paramount.

• Dimensions of 900 mm in height and 1000 mm in depth, combined with an impressive working capacity of 1.2 m³, enable efficient loading and transport of loose and organic materials – such as manure, silage, green waste, wood chips, compost, or sawdust.

• The robust construction with a weight of 375 kg ensures high mechanical resistance while maintaining stability and operational safety even during intensive use.

• The solid rear wall effectively prevents material from spilling out during transport, which improves operating comfort and helps maintain cleanliness in the loading area.

• Two hydraulic cylinders guarantee a powerful and even closing of the upper jaw – regardless of the material distribution or weight, which increases control over the load and improves operator precision.

• The large opening angle of the upper jaw allows for easy maneuvering in confined spaces – such as against silo walls or inside pens, significantly increasing the attachment's versatility.

• Ten tines on the upper section and eleven on the bottom section ensure excellent penetration into the material and its stable retention during transport, even over uneven terrain.

• Their well-thought-out spacing promotes an even distribution of forces, translating into effective and safe operation during every duty cycle.

• The body is manufactured from high-grade steel resistant to abrasion, impacts, and deformation – guaranteeing a long service life for the device and minimizing the need for repairs or service downtime.

• The standard EURO hitch enables quick and trouble-free connection to most machines available on the market, greatly simplifying daily operation.

• For users utilizing non-standard mounting systems, it is possible to produce a version tailored to a specific loader type.

• The 2400 mm wide model is an efficient, durable, and professional tool built for intensive work in environments where reliability and maximum productivity are key.
