Agrowow 3-bottom bed plow

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: BA03PZZ

- Manufacturer's name: Conventional plow

- Working width: 600 mm

- Weight: 210 kg

- Number of furrows: 3 (3-bottom)

- Power requirement: 32 HP

- Legs with furrow width: 300 mm

- Moldboards: semi-helical

- Under-frame clearance: 600 mm

- Wheel: narrow, bushed, metal

- Medium plowing

- Fixed working width

Optional extras:

- Bearing-mounted wheel (upon request)

A wheel integrated with bearings significantly improves the machine's guidance, especially when working on uneven and difficult terrain. Thanks to reduced rolling resistance, the wear on components such as the axle and hub is reduced, which translates into less frequent service downtime and lower operating costs. This type of solution increases the durability of the running gear while enhancing operator comfort, especially during long days of field work where vibration reduction is of key importance.

- Rubber wheel (upon request)

A wheel made of rubber is a practical and functional solution for working in diverse soil conditions. The flexible surface allows for better adaptation to terrain irregularities, resulting in effective shock absorption and increased stability of the plow. Additional advantages include quieter operation compared to steel wheels and a reduced risk of getting stuck in soft or wet ground. Such a wheel positively impacts the lifespan of the machine and the operator's working comfort.

- Coulter (upon request)

A coulter is an important working component mounted in front of the plow body, whose task is to cut through the top layer of soil and organic residues, such as straw, weeds, or catch crops. Its presence significantly facilitates proper furrow formation, improving plowing quality and reducing the risk of the machine clogging. The coulter proves particularly helpful in fields with a large amount of plant residue, enabling an even, aesthetic result and optimal soil preparation for further cultivation treatments.

Detailed Description:

• The 3-furrow conventional plow is a lightweight yet durable agricultural machine designed for medium plowing on light and medium soils.

• Thanks to its compact design and low net weight, it is ideal for smaller farms where maneuverability, simplicity of operation, and reliability in daily field work are what matter most.

• The machine is equipped with three working legs, each responsible for plowing at a width of 300 mm, resulting in a total working width of 600 mm.

• The fixed working width guarantees stable and repeatable results regardless of the type of ground, which facilitates subsequent agrotechnical procedures.

• The plow utilizes proven semi-helical moldboards, which enable effective turning of the furrow and good crumbling of the soil.

• Ground prepared in this way quickly achieves the proper structure that promotes healthy plant growth.

• An additional advantage of the plow is its under-frame clearance of 600 mm, which provides enough space to work in conditions with small amounts of plant residue without the risk of the machine clogging.

• As standard, it features a narrow, bushed metal wheel, which supports stable guidance of the machine and maintains a uniform working depth.

• The bushing increases wear resistance, and the metal construction of the wheel guarantees durability, even when working in less favorable terrain.

• With a weight of 210 kg and a power requirement of just 32 HP, this agricultural plow works perfectly with light tractors, ensuring efficient plowing without putting an excessive strain on the machine.

• It is an excellent solution for farmers who need a compact, solid, and easy-to-use tool for basic cultivation work – reliable in daily operation and tailored to farms with a smaller acreage.
