Agrowow 3-bottom bed plow ORLIK

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: BA03PZO

- Manufacturer's name: Conventional plow Orlik

- Working width: 750 mm

- Weight: 235 kg

- Number of furrows: 3 (3-bottom)

- Power requirement: 33 HP

- Legs with furrow width: 250 mm

- Under-frame clearance: 600 mm

- Wheel: narrow, bushed, metal

- Light plowing

- Fixed working width

Optional extras:

- Bearing-mounted wheel (upon request)

The use of a wheel with bearings is a practical solution that significantly improves the smoothness of the machine's operation, especially on difficult and uneven terrain. Thanks to reduced rolling resistance, the wear on key components such as the axle or hub is limited, which translates into fewer technical downtimes and lower maintenance costs. This solution increases the reliability of the entire running gear and, during long-term operations, significantly improves operator comfort by reducing vibrations.

- Rubber wheel (upon request)

A wheel made of rubber is a component that improves the machine's adaptation to varying field conditions. Its flexible structure adapts better to the contours of the terrain, effectively absorbing irregularities and reducing vibrations. It operates more quietly than metal versions, and additionally minimizes the risk of getting stuck on wet or soft soil. It improves the guiding stability of the plow and increases the durability of the entire working assembly.

- Coulter (upon request)

A coulter is a precise working element positioned in front of the plow body, responsible for pre-cutting the soil and cutting through plant residues – such as weeds, straw, or catch crops. Its presence significantly facilitates the furrow turning process, improving plowing quality and reducing the risk of the tool clogging. It is perfectly suited for working in fields with large amounts of organic residue, guaranteeing a clean, even surface for further stages of cultivation.

Detailed Description:

• The 3-furrow agricultural plow is a practical and compact tool created for light conventional land plowing on small and medium-sized cultivated areas.

• Thanks to its simple yet robust build, this moldboard plow performs excellently in daily field operations, ensuring easy handling, low requirements for the tractor, and precise performance even under more challenging conditions.

• The machine is equipped with three working bodies, each performing plowing at a width of 250 mm, resulting in a total working width of 750 mm.

• The fixed working width makes it easy to plan agrotechnical procedures and ensures uniform soil processing, which translates into good preparation for subsequent stages of cultivation, such as sowing or fertilizing.

• The under-frame clearance of 600 mm allows for smooth guidance of the machine even in the presence of small amounts of crop residues, reducing the risk of clogging and operational delays.

• The standard equipment includes a narrow, bushed metal wheel, which is responsible for maintaining the stability and depth of the plowing, regardless of soil conditions.

• The bushing ensures a longer lifespan for the rolling components, and the metal construction of the wheel ensures that this agricultural plow can also handle tougher terrain.

• With a net weight of 235 kg and a power requirement of just 33 HP, the 3-furrow plow is compatible with light and medium agricultural tractors without putting a strain on their drivetrain.

• Thanks to its compact dimensions and tight design, it provides good maneuverability and low fuel consumption, which is particularly important for farms that focus on economics and efficiency.

• It is an ideal option for farmers who need a simple, durable, and functional tool for basic field work.

• This model is also perfect for secondary tasks – such as on residential plots, vegetable gardens, or smaller acreages requiring regular plowing.
