Agrowow 4-bottom bed plow ORLIK

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: BA04PZO

- Manufacturer's name: Conventional plow Orlik

- Working width: 1000 mm

- Weight: 320 kg

- Number of furrows: 4 (4-bottom)

- Power requirement: 44 HP

- Legs with furrow width: 250 mm

- Under-frame clearance: 600 mm

- Wheel: narrow, bushed, metal

- Light plowing

- Fixed working width

Optional extras:

- Bearing-mounted wheel (upon request)

A wheel mounted on bearings is a practical and reliable solution that significantly improves the machine's performance, especially on uneven and difficult terrain. Reduced rolling resistance leads to less wear on components such as the hub and axle, resulting in less frequent maintenance and lower operating costs. The use of this system extends the lifespan of the running gear and, during longer working cycles, noticeably improves operating comfort by reducing the level of vibrations felt by the operator.

- Rubber wheel (upon request)

A rubber support wheel is a component that increases the efficiency and comfort of using the machine in varying field conditions. Thanks to its flexibility, it perfectly adapts to the contours of the terrain, effectively dampening shocks and limiting the transmission of vibrations to the plow frame. Compared to the steel version, it operates more quietly and performs better on wet, soft soils – reducing the risk of getting stuck and improving machine handling.

- Coulter (upon request)

A coulter is an important working element mounted in front of the plow body, designed to cut through the top layer of soil and plant residues such as straw, weeds, or catch crops. It facilitates furrow formation, aids in its proper turning, and significantly affects the overall quality of the plowing. The presence of a coulter prevents the machine from clogging, especially with large amounts of organic residue, and helps achieve an even, well-prepared field for subsequent agrotechnical procedures.

Detailed Description:

• The 4-furrow conventional plow is a durable and compact tool designed for light plowing on small and medium-sized farms.

• Its simple yet robust design ensures reliable performance in daily operations, while guaranteeing ease of use and low power requirements from the tractor.

• Equipped with four working bodies, each with a width of 250 mm, this agricultural plow offers a total working width of 1000 mm.

• The fixed working width ensures consistent plowing results and streamlines the planning of subsequent cultivation tasks, such as fertilizing or sowing.

• The 600 mm under-frame clearance allows for efficient operation even in the presence of crop residues, while minimizing the risk of machine clogging.

• The standard equipment includes a narrow, bushed metal wheel, which is responsible for guiding the plow at a constant depth and maintaining its stability when working on variable terrain.

• The bushed solution significantly increases the durability of the rolling system, and the steel construction of the wheel guarantees reliability even during long-term use in demanding conditions.

• With a weight of 320 kg and a power requirement of 44 HP, the 4-furrow plow can easily work with light and medium-class agricultural tractors without causing excessive fuel consumption or straining the drivetrain.

• It is an excellent choice for farmers looking for a durable, easy-to-use, and economical tool for basic plowing.

• It is perfectly suited for both large field tasks and smaller plots, ensuring precise soil preparation for further stages of cultivation.
