Agrowow disc harrow ALFA X4 3.15 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

Numer telefonu: +48 880 261 210 | +48 504 947 222

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: ALFAX4315

- Manufacturer's name: Disc harrow ALFA X4

- Width: 3150 mm

- Number of discs: 28

- Disc diameter: 460 / 510 / 560 mm

- Number of bearings: 8

- Weight: 830 kg

- Power requirement: 80-90 HP

- Efficiency: 1.9-5.4 ha/h

- Polish 510 mm boron steel disc

- Reinforced construction

- Hitch beam

- Powder-coated components

- Disc row spacing 120 cm

- 6-hole hubs

- Rubber roller damping system

- Universal hitch system for Cat. II and Cat. III suspension

- Rear tubular or string roller

Optional extras (at additional cost):

- String roller Ø300

A compact string roller designed for precise soil leveling. It effectively crushes small soil clods, improving its structure before sowing. Thanks to its lightweight design, it reduces rolling resistance, which facilitates its operation. It performs perfectly in crops requiring gentle treatment, ensuring uniform and well-prepared soil.

- Disc Ø560

A durable 560 mm diameter disc made of high-grade steel, used in disc harrows. It guarantees efficient cutting of plant residues, soil mixing, and loosening. High resistance to abrasive wear translates into a long service life. Thanks to its appropriate profile, it facilitates soil penetration even in difficult conditions.

- String roller Ø500

A larger version of the string roller, designed for intensive soil leveling and crushing. It improves soil aeration and increases its moisture retention capacity, which prevents excessive compaction. It is perfectly suited for crops requiring a uniform soil structure and thorough pre-sowing preparation.

- Tubular roller Ø500

A robust tubular roller that effectively stabilizes the ground after operation with a disc harrow. Its design allows for efficient soil compaction, helping to maintain its optimal moisture level. The special construction limits excessive compaction, leaving the ground with the appropriate structure for further agricultural work.

- Packer roller Ø500

A specialized roller designed for intensive soil compaction and breaking up larger clods of earth. Its unique design supports moisture retention and stabilizes the ground, which promotes better plant rooting. An ideal choice for crops where achieving an even and well-prepared soil is key.

- Roof roller Ø500

A roller designed for operation on light and medium soils, effectively loosening and leveling the field surface. Its design limits excessive soil drying and increases its moisture storage capacity. Additionally, it prevents erosion, improving conditions for subsequent cultivation stages.

- Croskill roller Ø500

A modern double-construction croskill roller, effectively breaking up compacted soil layers and improving its structure. As a result, the soil absorbs water better, which positively affects plant growth. It is ideal for crops where obtaining a perfectly prepared ground before sowing is crucial.

Detailed Description:

• The Agrowow ALFA X4 3.15 m disc harrow is a modern, versatile, and efficient agricultural machine designed for effective pre-sowing cultivation and other key soil preparation works.

• Its advanced construction and innovative technological solutions enable not only efficient loosening, compacting, and crushing of the soil, but also its leveling and covering seeds after sowing, which ensures optimal conditions for plant growth.

• The harrow, with a working width of 3150 mm, is equipped with 28 discs arranged in two rows, which ensures even mixing and aeration of the soil, improving its structure and moisture storage capacity.

• The discs, with a diameter of 460, 510, or 560 mm, made of high-grade boron steel, feature high resistance to abrasive wear and a long service life, allowing for intensive use in various field conditions.

• The disc row spacing of 120 cm enables effective soil crushing and its appropriate preparation for subsequent stages of cultivation.

• Thanks to the reinforced construction and the use of 6-hole hubs, the machine guarantees exceptional stability and durability even in demanding terrain conditions.

• The damping system based on rubber rollers effectively dampens vibrations and protects the structure against overloads, which increases the comfort of machine operation.

• The harrow is not only a tool for soil preparation before sowing – it also performs perfectly in eliminating weeds and mixing soil with mineral and organic fertilizers, making it an indispensable component for legume crop cultivation.

• Combining the disc harrow with a seed drill allows for simultaneous cultivation and sowing in a single pass, which significantly increases work efficiency, reduces fuel consumption, and accelerates agrotechnical processes.

• An automatic hitch beam and a universal suspension system of category II and III enable quick and easy connection of the machine to various tractor models.

• The disc harrow requires a tractor with a power range of 80-90 HP, making it compatible with a wide range of agricultural vehicles.

• The efficiency at a level of 1.9-5.4 ha/h allows for quick and effective soil preparation for sowing, which significantly accelerates field works.

• After harvesting, the harrow can also be used for post-harvest cultivation, preparing the field for subsequent sowing and effectively eliminating plant residues.

• The rear tubular or string roller additionally levels the soil surface, improving its moisture retention capacity and facilitating further cultivation treatments.

• All components of the construction have been finished with powder coating, which effectively protects the machine against corrosion and mechanical damage, extending its service life.

• The Agrowow ALFA X4 3.15 m disc harrow is a reliable and versatile agricultural tool that, thanks to its robust build, modern solutions, and high efficiency, significantly improves work productivity and crop quality, ensuring reliability for many seasons.
