Agrowow disc harrow TIGER 2.5 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: TH25

- Manufacturer's name: Disc harrow TIGER

- Width: 2500 mm

- Number of discs: 20

- Spacing between disc rows: 650 mm

- Disc diameter: 510 / 560 / 610 mm

- Working depth: 100-200 mm

- Weight: 1140 kg

- Power requirement: 90-120 HP

- Number of actuators: 2

- Polish 560 mm boron steel discs

- Reinforced construction

- Efficiency: 1.7-2.2 ha/h

- 6-hole hubs

- Rubber roller cushioning system

- Universal hitch system (Cat. II and III)

- Side screens

Optional extras (at additional cost):

- Packer roller

The packer roller is an element of the tillage aggregate designed for intensive soil compaction and leveling. Its use is particularly beneficial on heavy and cohesive soils, where it improves the substrate structure, reducing excessive loosening. Thanks to the packer roller, the soil gains better stability, which promotes better seed-to-soil contact and thus uniform crop emergence.

- V-profile roller

The V-profile roller works perfectly on light and medium soils, where its design allows for effective crushing and leveling of the soil surface. Its unique shape ensures uniform compaction, which positively affects water retention and limits excessive soil drying. This is an excellent solution for farmers looking for a way to improve crop quality in more demanding soil conditions.

- Croskill roller

The Croskill roller is distinguished by its double-row disc construction, thanks to which it intensively crushes the soil and eliminates large clods. It is particularly useful in pre-sowing cultivation, as it helps create an optimal soil structure, which translates into better conditions for sowing and uniform plant emergence. It works perfectly on medium and heavy soils, where it additionally improves soil load-bearing capacity and its moisture retention ability.

- Maintenance-free steel SKF hub

The maintenance-free steel SKF hub is an innovative solution that eliminates the need for lubrication and frequent maintenance, which significantly facilitates machine operation. Made of durable steel, it is resistant to high loads and difficult field conditions. Thanks to the use of this technology, the durability of the rollers and discs is increased, which minimizes the risk of failure and lowers operating costs. This is a reliable solution for farmers expecting high performance and durability of tillage machines.

- 610 mm disc

The 610 disc is a key element of tillage aggregates and disc harrows, which plays an important role in the soil preparation process. Its 610 mm diameter ensures effective cutting of crop residues and intensive soil mixing, which improves its structure and prepares the substrate for sowing. Made of high-quality steel, it is characterized by high resistance to abrasion and mechanical damage, which guarantees a long service life even with intensive use.

Detailed Description:

• The TIGER disc harrow is a modern agricultural machine designed for effective soil preparation for sowing.

• Thanks to its solid construction and high-quality components, it ensures effective soil mixing, crushing of crop residues, and improvement of its structure.

• The machine has a working width of 2500 mm, which makes it an ideal solution for medium-sized farms, offering high operating efficiency of 1.7-2.2 ha/h.

• Equipped with 20 working discs, arranged in two rows with a spacing of 650 mm, it allows for thorough and uniform loosening of the substrate.

• The user can choose discs with a diameter of 510, 560, or 610 mm, depending on the type of crop and soil conditions.

• As standard, the aggregate features Polish 560 mm boron steel discs, which are characterized by exceptional durability and abrasion resistance, allowing for intensive operation in demanding conditions.

• The adjustable working depth from 100 to 200 mm allows the machine to be adapted to the individual needs of the user.

• Thanks to the reinforced construction, the aggregate ensures reliability and long service life even during intensive operation.

• The cushioning system in the form of rubber rollers effectively reduces vibrations, protecting the structure from overloads and increasing operator comfort.

• Stability and failure-free operation are guaranteed by 6-hole hubs, which perform well in difficult field conditions.

• Additionally, side screens prevent soil from scattering outside the working area, which improves the precision and efficiency of cultivation.

• The disc harrow is equipped with a universal Cat. II and III hitch system, which allows for easy connection to various models of agricultural tractors.

• Thanks to the power requirement in the 90-120 HP range, the machine can cooperate with a wide range of tractors, ensuring smooth and efficient work.

• This is an excellent choice for farmers who expect high performance, durability, and ease of use.

• The disc harrow effectively prepares the soil for sowing, increasing crop efficiency and facilitating daily work on the farm.
