Agrowow disc harrow TIGER 4.0 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: TH40

- Manufacturer's name: Disc harrow TIGER

- Width: 4000 mm

- Number of discs: 32

- Spacing between disc rows: 650 mm

- Disc diameter: 510 / 560 / 610 mm

- Working depth: 100-200 mm

- Weight: 1750 kg

- Power requirement: 130-150 HP

- Number of actuators: 2

- Polish 560 mm boron steel discs

- Reinforced construction

- Efficiency: 2.5-4.2 ha/h

- 6-hole hubs

- Rubber roller cushioning system

- Side screens

- Universal hitch system (Cat. II and III)

Optional extras (at additional cost):

- Packer roller

The packer roller is an essential element of tillage aggregates, responsible for effective soil compaction and leveling. It works particularly well on heavy and compacted soils, improving their structure and preventing excessive loosening of the substrate. Its use makes the soil better prepared for sowing, which promotes better plant rooting and ensures uniform seed germination.

- V-profile roller

The V-profile roller is an ideal solution for working on light and medium soils, where it effectively crushes and levels the soil surface. Its special design improves the soil's ability to retain moisture, limiting excessive drying. As a result, crops have easier access to water, which positively influences their growth and development.

- Croskill roller

The Croskill roller is distinguished by a double-disc system that intensively crushes the soil and effectively eliminates larger clods. It is perfectly suited for preparing the substrate before sowing, ensuring optimal aeration and uniform compaction. Its use works particularly well on medium and heavy soils, where it additionally improves substrate stability and increases its moisture retention capacity.

- Maintenance-free steel SKF hub

The maintenance-free steel SKF hub is a modern solution that eliminates the need for frequent maintenance and lubrication, which significantly facilitates machine operation. Its durable construction is resistant to high loads and difficult working conditions, extending the service life of rollers and discs. Thanks to this solution, the risk of failure is minimized, and the operating costs of agricultural machinery are significantly reduced.

- 610 mm disc

The 610 mm diameter disc is a key component of tillage aggregates and disc harrows, playing a major role in the soil preparation process. Its large working surface allows for effective cutting of crop residues and intensive soil mixing, which positively influences its structure and readiness for sowing. Made of high-quality steel, it is characterized by exceptional resistance to abrasion and mechanical damage, guaranteeing a long service life even under intensive use.

Detailed Description:

• The TIGER disc harrow is a modern and effective agricultural machine, designed for precise soil preparation before sowing.

• Its solid construction and high-quality components ensure effective soil mixing, crushing of crop residues, and improvement of the substrate structure.

• The machine with a working width of 4000 mm is perfect for medium and large farms, offering an efficiency of 2.5-4.2 ha/h.

• Equipped with 32 working discs, arranged in two rows with a spacing of 650 mm, it ensures thorough and uniform soil loosening.

• The option to choose discs with a diameter of 510, 560, or 610 mm allows the machine to be adapted to various types of crops and soil conditions.

• As standard, the aggregate features Polish 560 mm boron steel discs, which are distinguished by high abrasion resistance, ensuring a long service life and reliability even in difficult working conditions.

• The adjustable working depth in the range of 100-200 mm allows for precise adjustment of work parameters to the user's requirements.

• The reinforced construction increases the machine's durability and its resistance to intensive use.

• The cushioning system in the form of rubber rollers effectively reduces vibrations, protecting the machine from excessive wear.

• 6-hole hubs guarantee high stability and reliability even in demanding field conditions. Side screens minimize soil scattering outside the working area, improving precision and cultivation efficiency.

• The machine is equipped with a universal Cat. II and III hitch system, which enables quick and easy connection to various tractor models.

• A power requirement in the range of 130-150 HP allows for effective cooperation with a wide range of agricultural tractors.

• This is an excellent choice for farmers who expect reliability, durability, and simplicity of operation.

• The TIGER disc harrow effectively prepares the soil for sowing, optimizing work time and increasing crop efficiency.
