Agrowow disc harrow TIGER II 3.0 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: SBTHII30

- Manufacturer's name: Disc harrow TIGER II

- Width: 3000 mm

- Number of discs: 24

- Disc diameter: 560 / 610 / 660 mm

- Disc row spacing: 900 mm

- Weight: 1090 kg

- Power requirement: 80-110 HP

- Efficiency: 2.1-3.3 ha/h

- Polish 560 mm boron steel disc

- Reinforced construction

- 6-hole hubs

- Rubber roller damping system

- Side screens

- Universal mounted hitch system for Cat. II and Cat. III

- Rear tubular or string roller

- Powder-coated components

Optional extras (at additional cost):

- Packer roller

The packer roller is an essential element of tillage machinery, responsible for effective soil compaction and leveling. Its precise construction allows for effective crushing of larger soil clods, improving ground structure and increasing its moisture retention capacity. By stabilizing the soil, it supports proper plant rooting and creates optimal conditions for their growth.

- Roof roller

The roof roller is an ideal solution for light and medium soils, where its task is accurate crushing and leveling of the surface. Its special design prevents excessive soil drying and increases its moisture storage capacity, which has a significant impact on plant development. Additionally, the roof roller counteracts soil erosion, improving its stability and structure.

- Croskill roller

The croskill roller is an innovative solution whose double construction effectively breaks up compacted soil layers and levels the field surface. It is particularly useful in preparing the ground for sowing, as it improves its structure and increases the soil's ability to retain moisture. It works great on medium and heavy soils, eliminating excessive compaction, stabilizing the ground, and supporting crop development.

- Double roof roller

The double roof roller is an advanced technology that loosens and levels the soil even more effectively. Thanks to its construction, it efficiently crushes soil clods, improves ground structure, and limits its excessive drying out. Additionally, it increases the soil's moisture retention capacity, which beneficially influences plant growth and improves conditions for further cultivation.

- Maintenance-free SKF hubs

Maintenance-free SKF hubs are an innovative solution that eliminates the need for regular maintenance and lubrication, which significantly simplifies the use of agricultural machinery. Made of durable materials, they ensure high resistance to heavy loads and intensive operation. Their use minimizes the risk of failure and reduces downtime, which lowers operating costs and increases work efficiency on the farm.

- Polish 610 mm boron steel discs

Discs with a diameter of 610 mm, made of high-grade boron steel, are characterized by exceptional durability and wear resistance. Their precisely designed shape ensures effective cutting of crop residues, intensive soil mixing, and its optimal preparation for further cultivation. A solid construction guarantees a long service life and reliability even in the toughest field conditions.

- Transport trolley + drawbar (+800 kg)

A transport trolley with a drawbar is a practical solution that facilitates moving the machine both in the field and on access roads. A solid construction ensures stability during transport, and an ergonomically designed drawbar allows for quick and convenient connecting and disconnecting of the machine, increasing the comfort of use.

Detailed Description:

• The TIGER II disc harrow is a versatile and robust agricultural machine, designed with intensive pre-sowing soil cultivation and other key field work in mind.

• Its universality makes it perform excellently both in traditional cultivation methods and in simplified systems.

• The main functions of the harrow include soil loosening, compacting, crushing compacted clods, covering seeds after sowing, weed elimination, and mixing soil with mineral and organic fertilizers.

• It also works perfectly in post-harvest cultivation, effectively preparing the field for subsequent sowing.

• The option to combine the harrow with a seed drill allows for simultaneous cultivation and sowing, which increases work efficiency and reduces fuel consumption.

• The machine, with a working width of 3000 mm, has been equipped with 24 discs that ensure effective aeration and loosening of the soil.

• Discs with a diameter of 560, 610, or 660 mm, made of Polish boron steel, are characterized by high abrasion resistance and a long service life.

• A disc row spacing of 900 mm guarantees effective soil mixing, improving its structure and moisture storage capacity.

• Reinforced construction and the use of 6-hole hubs ensure the machine's stability and resistance to heavy loads during work.

• A damping system using rubber rollers effectively reduces vibrations and protects the machine structure against overloads, ensuring smooth and comfortable work.

• Side screens prevent soil scattering outside the working area, which increases precision and cultivation efficiency.

• The rear tubular or string roller additionally levels the soil surface, supporting its moisture retention capacity, which favors better plant growth.

• A universal category II and III hitch system allows for easy connection of the harrow to various tractor models.

• A weight of 1090 kg guarantees stability during work, and a power requirement in the range of 80-110 HP makes the machine work with a wide range of agricultural tractors.

• Thanks to an efficiency of 2.1-3.3 ha/h, the harrow ensures fast and effective soil preparation for sowing, optimizing work time on the farm.

• All elements of the machine have been covered with a powder coating, which provides effective protection against corrosion and mechanical damage, extending the device's lifespan.

• Solid construction, modern technological solutions, and high-quality materials make the TIGER II disc harrow an ideal solution for farmers who expect maximum efficiency, durability, and comfort of use.
