Agrowow disc harrow TIGER JUNIOR 2.2 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: TJII22

- Manufacturer's name: Disc harrow TIGER JUNIOR

- Width: 2200 mm

- Number of discs: 18

- Spacing between disc rows: 750 mm

- Disc diameter: 460 / 510 / 560 mm

- Working depth: 100-200 mm

- Weight: 630 kg

- Power requirement: 45-65 HP

- Efficiency: 1.5-2.0 ha/h

- Polish 560 mm boron steel discs

- Reinforced construction

- 6-hole hubs

- Rubber roller cushioning system

- Side screens

- Universal hitch system (Cat. II and III)

- Rear tubular or string roller

- Powder-coated parts

Optional extras (at additional cost):

- Packer roller

The packer roller is a key element of tillage machinery, responsible for effective soil compaction and leveling. Its specially designed construction allows for efficient crushing of larger soil clods, which improves soil structure and facilitates moisture absorption. Thanks to this, the soil becomes more stable, which promotes proper root development and ensures optimal conditions for plant growth.

- V-profile roller

The V-profile roller is an excellent solution for light and medium soils, where it effectively crushes and levels the field surface. Its construction prevents excessive soil drying and improves its water retention capacity, which is crucial for plant development. Additionally, the V-profile roller reduces the risk of soil erosion, which positively impacts its quality and structure.

- Croskill roller

The Croskill roller is an innovative solution that, thanks to its double-disc construction, effectively crushes compacted soil clods and levels the field. It is particularly useful in the seedbed preparation stage, as it improves soil structure and increases moisture retention capacity. It works perfectly in medium and heavy soils, eliminating overly compacted layers, stabilizing the subsoil, and supporting plant development.

- Polish 560 mm boron steel discs

Discs with a diameter of 560 mm, made of high-quality boron steel, are distinguished by exceptional durability and abrasion resistance. Their well-thought-out design enables effective cutting of crop residues, thorough soil mixing, and optimal preparation for further tillage operations. Thanks to solid materials, the discs perform excellently in demanding field conditions, ensuring reliability and long service life.

- Maintenance-free SKF hubs

Maintenance-free SKF hubs are a modern solution that eliminates the need for frequent maintenance and lubrication, facilitating the operation of agricultural machinery. Made of durable materials, they are characterized by high resistance to intensive loads and long-term work. Their use minimizes the risk of failure and downtime, which translates into lower operating costs and increased cultivation efficiency.

Detailed Description:

• The TIGER JUNIOR disc harrow is a versatile and compact agricultural machine, designed for effective pre-sowing cultivation and basic field tasks.

• Its construction enables effective loosening, pressing, and crushing of the soil, creating optimal conditions for plant growth.



• The 2200 mm working width machine is equipped with 18 working discs arranged in two rows, which ensures uniform soil aeration and thorough loosening.

• Thanks to the adjustable working depth in the range of 100-200 mm, the harrow can be adapted to different soil conditions and specific crop requirements.



• TIGER JUNIOR performs excellently in pre-sowing cultivation as well as in mixing crop residues and organic fertilizers, which positively impacts soil fertility.

• It can also be used for soil refinement in a simplified no-till system, increasing its versatility.

• Additionally, the ability to work with a seed drill allows for simultaneous cultivation and sowing, which translates into time savings and higher work efficiency.



• The solid construction of the machine guarantees its reliability and long service life, even under intensive use.

• Discs with diameters of 460, 510, or 560 mm are made of high-quality boron steel, which provides them with high abrasion resistance and long durability.

• The reinforced build and the use of 6-hole hubs make the harrow stable and resistant to heavy loads during work.

• The cushioning system based on rubber rollers effectively reduces vibrations, protecting the structure from overloads.

• Additionally, side screens prevent soil from spilling outside the working area, increasing work precision.



• The disc harrow is equipped with a rear tubular or string roller, which levels the field surface and supports moisture retention in the soil, which is of key importance for plant growth.

• The machine requires a tractor with a power of 45 to 65 HP, ensuring broad compatibility and economical operation with various agricultural vehicles.



• An efficiency of 1.5-2.0 ha/h makes it an excellent choice for farmers looking for effective and productive equipment for soil cultivation.

• The universal Cat. II and III hitch system enables fast and convenient connection to various tractor models.

• All elements of the machine are covered with powder coating, which provides protection against corrosion and increases resistance to mechanical damage, extending the device's durability.

• Modern construction and solid workmanship make TIGER JUNIOR an ideal solution for farmers who expect reliability, high efficiency, and ease of use.
