Agrowow hydraulic disc harrow ROTOS 4.5 m

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Agrowow

- Catalogue number: STBTH45

- Manufacturer's name: Hydraulic disc harrow ROTOS

- Width: 4500 mm

- Number of cylinders: 4

- Number of discs: 36

- Disc diameter: 560 / 610 / 660 mm

- Disc row spacing: 1200 mm

- Weight: 2800 kg

- Power requirement: 140-170 HP

- Efficiency: 3.5-5.5 ha/h

- Polish 560 mm boron steel disc

- Reinforced construction

- 6-hole hubs

- Rubber roller damping system

- Side screens

- Universal mounted hitch system for Cat. II and Cat. III

- Rear tubular or string roller

- Powder-coated components

Optional extras (at additional cost):

- Packer roller

The packer roller is an indispensable element of cultivation machinery, ensuring effective soil compaction and leveling. Its specially designed construction enables efficient crushing of larger soil clods, which beneficially affects the ground structure and improves its moisture absorption capacity. Thanks to the use of this roller, the soil becomes more stable, promoting better plant rooting and creating ideal conditions for their growth.

- Roof roller

The roof roller is an excellent solution designed for operation on light and medium soils, where it effectively crushes and levels the field surface. Its unique construction prevents excessive soil drying and increases its moisture retention capacity, which is important for proper plant development. Additionally, the roof roller helps protect the soil against erosion, improving its stability and structure.

- Croskill roller

The croskill roller is a modern solution that, thanks to its double construction, effectively breaks up compacted soil layers and levels the field surface. It is particularly useful during the pre-sowing soil preparation stage, as it improves its structure and increases its moisture storage capacity. It works great on medium and heavy soils, eliminating excessive compaction, stabilizing the ground, and supporting plant growth.

- Double roof roller

The double roof roller is an advanced technology that loosens and levels the soil even more effectively. Thanks to its construction, it efficiently crushes soil clods, improves the ground structure, and prevents its excessive drying. Furthermore, it increases the soil's moisture retention capacity, which promotes better plant growth and optimizes conditions for further cultivation works.

- Maintenance-free SKF hubs

Maintenance-free SKF hubs are a modern solution that eliminates the need for frequent maintenance activities and lubrication, significantly simplifying the use of agricultural machinery. Made of high-strength materials, they stand out with resistance to heavy loads and intensive work. Their application reduces the risk of failures and downtime, translating into lower operating costs and higher work efficiency in the field.

- Polish 610 mm boron steel discs

Discs with a diameter of 610 mm, made of high-grade boron steel, are characterized by exceptional resistance to wear and abrasion. Their precisely designed shape ensures effective cutting of crop residues, intensive soil mixing, and its optimal preparation for subsequent stages of cultivation. The robust construction guarantees long service life and reliability in even the most demanding field conditions.

- Transport trolley + drawbar (+1150 kg)

A transport trolley with a drawbar is a practical solution that facilitates moving the machine both in the field and on access roads. The solid construction ensures stability during transport, and the ergonomically designed drawbar allows for easy connecting and disconnecting of the machine, significantly increasing the comfort of use.

Detailed Description:

• The ROTOS disc harrow is a modern and durable agricultural machine, created for intensive and precise soil cultivation.

• Its advanced construction and innovative technological solutions make the machine perform excellently both in traditional cultivation methods and in reduced tillage systems.

• A working width of 4500 mm allows for quick and effective soil preparation for sowing, which significantly accelerates field works.

• The machine is equipped with 36 discs with a diameter of 560, 610, or 660 mm, made of high-quality boron steel, which ensures their resistance to abrasive wear and long durability.

• An optimal disc row spacing at a level of 1200 mm enables precise mixing and loosening of the soil, supporting its structure and moisture retention.

• A hydraulic system with four cylinders allows for smooth adjustment of the machine, adapting its operation to various soil conditions.

• Damping in the form of rubber rollers effectively reduces vibrations, protecting the structure against overloads and increasing user comfort.

• The durable frame and the use of 6-hole hubs guarantee high longevity of the machine even under intensive operation.

• The rear tubular or string roller additionally levels the field surface, supporting moisture retention in the soil and preparing it for the next stages of cultivation.

• Thanks to the universal hitch system of category II and III, the harrow can be easily connected to various tractor models with power ranging from 140 to 170 HP, which increases its versatility.

• An efficiency at a level of 3.5-5.5 ha/h makes it an excellent choice for large-area farms that expect maximum productivity.

• Side screens support precise work, and high-quality powder coating protects the structure against corrosion and mechanical damage.

• The ROTOS disc harrow is an ideal solution for farmers looking for an efficient, durable, and easy-to-operate machine that increases crop quality and optimizes the soil preparation process.
