Metal-Technik chain harrow 3 m / 4 rz / 0

Want to determine the specifications and customize a meadow harrow to your individual needs?

We can prepare a mounting system for any type of equipment — tractors, excavators, loaders, forklifts, and many other machines.

Contact our sales engineer!

Email address: sklep@agrowow.pl

We will gladly help you choose the right configuration and answer any questions you may have.

- Manufacturer: Metal-Technik

- Catalogue number: MT340WB

- Manufacturer's name: Chain harrow

- Width: 3000 mm

- Height: 950 mm

- Weight: 400 kg

- Cylinders: 0

- Hitch/Mounting: Three-point linkage (TUZ) Cat. I or II

- Version: 4-row

- Folding: Manual

- Breaks up soil crusts formed during winter

- Firms the soil and destroys small, germinating weeds

- The frame and mesh consist of toothed, cast-iron working elements

- Special hinges ensuring stability during operation and transport

- The chain harrow meshes are equipped with reversible working elements for dual-purpose use

Detailed Description:

• The 3000 mm wide, 4-row chain harrow is a compact yet solid agricultural tool designed for the care and maintenance of smaller-scale meadows, pastures, and farmland.

• Due to its size, it is perfectly suited for smaller farms and seasonal operations where efficiency and ease of use are key factors.

• Thanks to its four-row configuration, the machine effectively levels the terrain, breaks up soil crusts formed over the winter, firms the soil, and eliminates young weeds in their germination phase, thereby improving plant growth conditions and the overall soil structure.

• With a construction height of 950 mm and a weight of 400 kg, it ensures appropriate downward pressure against the ground, translating into effective performance even on uneven surfaces.

• The manual frame folding system makes the machine simple in design, independent of external hydraulic systems, and less prone to breakdowns — a feature highly valued by users who prioritize durability and reliability.

• The three-point linkage (TUZ) Cat. I or II hitch enables quick and easy connection to most standard tractor models, increasing the machine's overall versatility.

• The working elements, made of durable cast iron, feature sharp tines that efficiently loosen and clear the soil surface of molehills and debris.

• Thanks to their fully reversible design, the tines can be turned over once one side is worn, which extends the lifespan of the components and reduces operating costs.

• Excellent stability during both fieldwork and transport is guaranteed by special, reinforced hinges that perform reliably even in variable terrain conditions.

• The 3000 mm, 4-row chain harrow is a functional and long-lasting solution for farmers seeking reliable equipment for the maintenance and reclamation of green areas.
